Engine makeTATA Cummins
Engine modelB 180 20 (Euro 2)
Capacity (cc)5883
LayoutDiesel inline 6
Engine typeTurbo intercooled
Power kw at r/min132 @ 2500
Torque Nm at r/min650 @ 1500
Transmission make / modelGBS – 750
Transmission typeSynchromesh
ShiftManual
No. of gears forward6
First gear ratio6.58
Top gear ratio0.77
Overall height2859
Overall length (mm)9047
Max width (mm)2440
Front overhang1515
Rear overhang2337
Wheelbase (mm)5195
CA – cab to bogie/ rear axle (mm)4570
GVM (kg)14900
V (kg)14900
GCM (kg)21400
D/T (kg)21400
Permissible body & payload (kg)9680
Tare – total (T) (kg)5220
Permissible rear axle weight (kg)9000
Permissible front axle weight (kg)6000
Manufacturers rear axle weight (kg)9000
Manufacturers front axle weight (kg)6000
Clutch typeSingle
Diameter (mm)380
Reduction typeSingle
Final ratio5.857
Brakes typeFull air dual
FrontDrums
Rear Drums
Anti-lock braking-system (ABS)Standard
Fuel tank capacity (Ltrs)350
Size & ply rating11.00R22.5 – 16PR
